    High Power Mobile Phone Signal Repeater Tri Band 43dBm CDMA800/GSM850 PCS1900 AWS 2100MHz

    Ask Lasest Price
    Brand Name : ChingKong
    Model Number : CKJ-43CPA
    Certification : CE
    Price : negotiate
    Payment Terms : T/T, Western Union,Money Gram
    Supply Ability : 10000 per month
    Delivery Time : 30 Working Days After Received Payment
    • Product Details
    • Company Profile

    High Power Mobile Phone Signal Repeater Tri Band 43dBm CDMA800/GSM850 PCS1900 AWS 2100MHz

    Product Description

    High Power Tri Band 43dBm CDMA800/GSM850 PCS1900 AWS 2100MHz Outdoor Signal Mobile Booster Cellphone Repeater

    High Power Tri Band 43dBm CDMA800/GSM850 PCS1900 AWS 2100MHz Outdoor Signal Mobile Booster Cellphone Repeater

    FrequencyRangeUplinkDownlink
    GSM900+1800+3G890- 915/1710 - 1785/
    1920 - 1980MHz
    935 - 960/1805 - 1880/
    2110 - 2170MHz
    EGSM900+1800+3G880- 915/1710 - 1785/
    1920 - 1980MHz
    925 - 960/1805 - 1880/
    2110 - 2170MHz
    GSM900+1800+LTE2600890- 915/1710 - 1785/
    2500 - 2570MHz
    935 - 960/1805 - 1880/
    2620 - 2690MHz
    GSM850+1900+AWS2100824 - 849/1850 - 1910/
    1710 - 1755MHz
    869 - 894/1930 - 1990/
    2110 - 2155MHz
    GSM850+1900+LTE2600824 - 849/1850 - 1910/
    2500 - 2570MHz
    869 - 894/1930 - 1990/
    2620 - 2690MHz
    1800+3G +LTE26001710 - 1785MHz/
    1920 - 1980MHz/
    2500 - 2570MHz
    1805 - 1880MHz/
    2110 - 2170MHz/
    2620 - 2690MHz
    LTE700+GSM850+1900777 - 787/824 - 849/
    1850 - 1910MHz
    746 - 756/869 - 894
    1930 - 1990MHz
    Max. Input Level (Non-Destructive)-10dBm
    Max. Output Power (customizable)33-43dBm
    Max. Gain≥ 90dB
    GainAdjustment Range1~31 dB @ step of 1dB
    Voltage Standing Wave Ratio (VSWR)< 1.5
    Spurious EmissionWithin working band≤ -15dBm/30kHz
    Out of working band
    (Δf > 2.5MHz)
    9kHz~1GHz: ≤ -36dBm/30kHz
    1GHz~12.75GHz: ≤ -30dBm/30kHz
    Noise Figure≤ 5dB
    In-Band Ripple≤ 3dB
    Third-Order Intermodulation≤ -45dBc/30kHz (measured under rated output power)
    System Delay≤ 5.0μSe
    I/O Impedance50Ω
    RF ConnectorN-Type (Female) / changeable / bottom of casing
    TemperatureRangeOperation: -25°C ~ +55°C / Storage: -30°C ~ +60°C
    RelativeHumidity Range≤ 95% (non condensing)
    Power Supply (customizable)DC -48V / AC 220V, 50/60Hz / AC 110V, 50/60Hz
    Backup Power Supply (optional)4 hours
    Casing LevelIP65
    Dimensions750x500x340mm
    Weight60kg
    NMS Monitoring Function (optional)Real-time alarm for door status, temperature, power supply, LNA, VSWR, self-oscillation, etc. Remote control such as turn on/off, increasing/decreasing output power, etc. Real-time status for output/input power, UL/DL gain, all status of repeater etc.

    User's Manual

    The Tri Band RF Repeater (RFR) is the kind of repeater used most frequently. It has a simple structure to transparently convey and amplify the wireless signal (at the same frequency) between the BTS (Base Transceiver Station) and mobiles in Dual wireless network.
    The Dual Band RFR is working as a relay between the BTS and mobiles. It picks up the signal from the BTS via the Donor Antenna, linearly amplifies the signal and then retransmits it via the Coverage Antenna (or the Indoor Signal Distribution System) to the weak/blind coverage area. And the mobile signal is also amplified and retransmitted to the BTS via the opposite direction.


    Features:
    * Aluminum-alloy casing with IP65 protection has high resistance to dust, water and corroding;
    * Highly selective channel selector can process multiple channels simultaneously;
    * No interference to BTS by adopting linear amplifier with high gain and low noise;
    * Adopting filter with highly selectivity and low insertion loss eliminates interference between uplink and downlink;
    * USB port provides a link to a notebook for local supervision or to the built-in wireless modem to communicate with the NMS (Network Management System) that can remotely supervise repeater's working status and download operational parameters to the repeater.
