Product Information
Name: Full Bands 16 Antennas Wireless Signal Jammer For 3G 4G Wi-Fi GPS
LOJACK Output power 40Watt Shielding Radius Up to 40m
Model: CKJ-1601A16
Color: Black
Basic Specifications
Jam Signal Type:1:CKJ-1601A16-B:Full Bands Mobile Phone 4G/3G/2G +WiFi2.4G5.8G+
GPSL1L2 +Walkie-Talkie UHF/VHF+ Wireless Camera 1.2GHz
2:CKJ-1601A16-A: Full Bands Cellphone 4G/3G/2G +WiFi2.4G5.8G+
GPSL1L2 + Full Bands Walkie-Talkie & Wireless Headset/Microphone
Output Power:Total 40W,1-3W each band
Jam Radius:2-40meters
Power Supply:AC110-240V to DC12V
Cooling System:High efficiency aluminum alloy radiator, Build-in 4 cooling fan
Working Time:Not-stop Working
Product Size:410x 238x 60 mm(not Include Antenna)
Product Weight: appr.6.5kg
Package Contents:Jammer Host x 1, AC adapter x 1,antenna x16,Car storage battery
cable x1
Product Description
This is designed with 16 Antennas Full Bands 130Mhz-6GHz for mobile
phone GSM 3G 4GLTE signal which bring us a strong jamming ability.
And it can not only cut off all 3G 4G mobile phone signals, but
also jam Wi-Fi GPS LOJACK, RF 315 MHz 433MHz , VHF UHF
Walkie-Talkie & Wireless Headset/Microphone signals. all-in-one
jammer is power full to blocks all the signals, Jamming frequencies
the jamming radius up to 40meters
Advantages
Full bands 16 chancel design, Customized for special frequency band
High output power, Total up to: 40W , jamming up to 40m (Still
depends on the strength signal in given area)
External Omni-directional antennas all the TX frequency covered
down link only
With Car storage battery Charger DC12V can be used in car
Built-in good cooling system inside, Working non-stopped
Can adjust or turn off any single band without influencing the
other bands operation
OEM Customized Service
Customized for special frequency band , 5GLTE 3.6GHz, etc
Silkscreen OEM service can be offered
Application
It can be applied at meeting rooms, conference rooms, museums,
galleries, theatres, concert halls, churches, temples, restaurants,
classrooms, training centers, factories, banks, trains, bus and
more Places that require silence, confidentiality and information
security
For some locations of special purpose such as hospitals, gas
stations and more, please do field test first to make sure no
interference happened to the normal operation of their equipment
and instrument
| Key technical specifications: CKJ-1601A16-B |
| Channel | Output port | Frequency range | Average out-putting power |
| 1 | VHF1 | 130-190MHz | 35dbm / 3W |
| 2 | UHF2 | 190-300MHz | 35dbm / 3W |
| 3 | UHF3 | 300-400MHz | 35dbm / 3W |
| 4 | UHF4 | 400-500MHz | 35dbm / 3W |
| 5 | 4G1 LTE 700 | 700-803 or 790-826MHz | 35dbm / 3W |
| 6 | 4G2 LTE 1700 | 1710-1780MHz | 33dbm / 2W |
| 7 | CDMA | 851-894MHz | 35dbm / 3W |
| 8 | GSM | 925-960MHz | 35dbm / 3W |
| 9 | DCS&PCS | 1805-1990MHz | 33dbm / 2W |
| 10 | 3G | 2110-2170MHz | 33dbm / 2W |
| 11 | 4G LTE 2600 | 2500-2690 MHz | 30dbm / 1W |
| 12 | Wi-Fi 2.4G+4G2300 | 2300-2500MHz | 30dbm / 1W |
| 13 | Wi-Fi 5.8G | 5725-5850MHz | 30dbm / 1W |
| 14 | GPSL1 | 1570-1580MHz | 33dbm / 2W |
| 15 | GPSL2+L5 | 1170-1280MHz | 33dbm / 2W |
| 16 | LOJACK& XM radio | 167-175MHz | 35dbm / 3W |
| The below frequencies you can instead of above one to combined 16
bands |
| Option | WIFI5.2G | 5100-5500MHz | 30dbm / 1W |
| WIFI5.8G | 5500-5900MHz | 30dbm / 1W |
| WiFi3.6G | 3500-3600MHz | 30dbm / 1W |
| Power supply: AC adapter 50 to 60Hz, (110-240V AC-12V DC) Car
storage battery Charger DC12V |
| Dimensions: (length ,width, height) 410x 238x 60mm(not Include
Antenna) |
| Packing size: 49*44*15cm Net weight: 6kg Gross weight: 7.0kg |
Total power:40W
Shielding radius: (2-40) meters At -75dBm
Still depends on the strength signal in given area, Shielding
radius of VHF/UHF signal about 10meters |
| Warranty: one year from delivery date |
